H-FLOW-10 Series

H-FLOW-10 Series

H-Flow-10 series is built on the patented microreaction hydrogenation technology of Tsinghua University, which mixes highly pure hydrogen with continuously flowing reactants in a micropacked column loaded with catalysts and reactants.

Features

• It can be connected directly to a hydrogen cylinder. You can also choose a high-pressure, high-purity hydrogen generator.




• You have full control over the entire hydrogenation process to avoid differences from batch to batch.




• By shortening the reaction time to within 3 minutes, the hydrogenation process is improved.




• The reactor is small, and the device is inherently safe.




• It can screen conditions, prepare products on scales of milligrams and grams, and evaluate catalyst life.




• A sampling port allows real-time sample collection.




• The high-throughput version allows for kilogram-scale product preparation.




• The instrument is small enough to fit in a fume hood.



• With a maximum reaction temperature of 200℃ and a system working pressure of 10 MPa, it is suitable for a wide range of hydrogenation applications.

• When combined with inline UV-visible and Fourier mid-infrared spectrometers, real-time inline monitoring and analysis are possible.




• An optional inline automatic sample collector can save the trouble of manual sampling by collecting hydrogenation products at regular intervals.

Specifications
